AGl Part Number
|
Outer Diameter
|
Yield Load
|
Ultimate Load
|
Unit Weight (kg/m)
|
T3016
|
30 mm
|
42.7 Kips (190kN)
|
55.1 Kips (245kN)
|
2.7
|
T3011
|
30 mm
|
58.5 Kips (260kN)
|
72.0 Kips (320kN)
|
3.3
|
T4020
|
40 mm
|
95.6 Kips (425kN)
|
121.4 Kips (540kN)
|
5.6
|
T4016
|
40 mm
|
118.1 Kips (525kN)
|
148.4 Kips (660kN)
|
7.0
|
T5226
|
52 mm
|
164.2 Kips (730kN)
|
208.0 Kips (925kN)
|
10.0
|
T7356
|
73mm
|
186.6 Kips (830kN)
|
232.7 Kips (1035kN)
|
11.1
|
T7345
|
73 mm
|
285.6 Kips (1270kN)
|
356.4 Kips (1585kN)
|
17.8
|
T10378
|
103 mm
|
404.8 Kips (1800kN)
|
510.5 Kips (2270kN)
|
24.9
|
